Switch/Relay, 1/2 gang+1 relay, Future linear
For switching 127 V~/230 V~ consumers. With integrated switch actuator. Switching function is available also without prior programming (pre-configured). Configuration can be changed later via the web interface (groups, scenes, etc.). For contacting 1gang rocker 6230-10-xxx, 6231-10-xxx, 6232-10-xxx, 6233-10-xxx und 6234-10-xxx. The bus can be connected via enclosed terminal block. When installing in the flush-mounted box, a spatial division between the bus cable and 127 V/230 V installation cable is to be adhered to! If this minimum distance is not possible, use electronic boxes or insulating tubes.
| Specification | |
|---|---|
| Voltage Range | 230 V |
| Rated Current (In) | 10 A |
| Maximum Switching Power | 2300 W |
| Number of Outputs | 1 |
| Number of LEDs | 0 |
| Maximum Number of Switching Outputs | 1 |
| Compatible Bus Systems | free@home |
| Product Range | ABB-free@home® |
| Load Type | ohmic |
| Battery Weight | 0 g |
| Number of Batteries | 0 |
